ANNIKA
Kirloskar Residential Water Pressure ANNIKA-I and ANNIKA-II pumps feature a Thermal Overload Protector for motor protection from overloading. This 0.5 HP and 1HP self-priming water pump is suitable for the voltage range 180 to 260 volts (Single Phase), thus perfectly suited for water supply to overhead tanks in bungalows, gardens, fountains, small farm irrigation, Sumps & water tanks.
PRIMARY USAGE
- Water supply to overhead tanks in bungalows
- Domestic water supply
- Feed water to RO plants
- Construction sites
- Lawn sprinklers
- Garden and fountains
- Car washing
ANNIKA - I (Bronze)
- Head Range: 6-24m
- Capacity Range: 2600 to 700 LPH
- Power Rating: 0.75 kW/1 HP
- Phase: Single
- Voltage Range: 160-260 Volts
- Insulation: ‘B’ Class
ANNIKA - II (Bronze)
- Head Range: 6-21m
- Capacity Range: 2000 to 500 LPH
- Power Rating: 0.37 kW/0.5 HP
- Phase: Single
- Voltage Range: 160-260 Volts
- Insulation: ‘B’ Class
- Impeller: Brass
- Delivery Casing: Cast Iron
- Motor Body: Aluminum
- Shaft: Carbon Steel
- Cover NDE: Aluminum
- Mechanical Seal: Carbon Vs. Ceramic
- High Efficiency and Energy Saving Design
- Wide Voltage Range
- Shielded Ball Bearing
- Dynamically Balanced Rotating Parts
- Easy Maintainable Designs
- High Suction Lift
- Enhanced Safety Features
- Cathodic Electro Deposition (CED) Coating
- Light Weight and Compact Design
- Water supply to overhead tanks in bungalows
- Domestic water supply
- Feed water to RO plants
- Construction sites
- Lawn sprinklers
- Garden and fountains
- Car washing
ANNIKA - I (Bronze)
- Head Range: 6-24m
- Capacity Range: 2600 to 700 LPH
- Power Rating: 0.75 kW/1 HP
- Phase: Single
- Voltage Range: 160-260 Volts
- Insulation: ‘B’ Class
ANNIKA - II (Bronze)
- Head Range: 6-21m
- Capacity Range: 2000 to 500 LPH
- Power Rating: 0.37 kW/0.5 HP
- Phase: Single
- Voltage Range: 160-260 Volts
- Insulation: ‘B’ Class
- Impeller: Brass
- Delivery Casing: Cast Iron
- Motor Body: Aluminum
- Shaft: Carbon Steel
- Cover NDE: Aluminum
- Mechanical Seal: Carbon Vs. Ceramic
- High Efficiency and Energy Saving Design
- Wide Voltage Range
- Shielded Ball Bearing
- Dynamically Balanced Rotating Parts
- Easy Maintainable Designs
- High Suction Lift
- Enhanced Safety Features
- Cathodic Electro Deposition (CED) Coating
- Light Weight and Compact Design
CATALOGUE
ANNIKA - I & II
Mini Range Pump (Bronze) - Installation Manual
