JALHASTI
- Enquire Now
Max Head:
Upto 6 to 36 mMax Capacity:
Upto 2900 to 820 LPH
Product Description
- Gardens and fountains
- Feed water to RO plants
- Domestic water supply
- Water supply to overhead tanks in bungalows
- Construction sites
- Car washing
- Lawn sprinklers
Product Details
SPECIFICATIONS
JALHASTI - (GOLD)
Model Jalhasti-II (Gold)
- Head Range: 6-36m
- Capacity Range: 2900 to 820 LPH
- Power Rating: 0.37 kW/0.5 HP
- Phase: Single
- Voltage Range: 180-260 Volts
- Insulation: ‘F’ Class
Model Jalhasti-I (Gold)
- Head Range: 6-50m
- Capacity Range: 4280 to 1000 LPH
- Power Rating: 0.75 kW/1.0 HP
- Phase: Single
- Voltage Range: 180-260 Volts
- Insulation: ‘F’ Class
MATERIAL OF CONSTRUCTION
- Impeller: Brass
- Delivery Casing: Cast Iron
- Motor Body: Aluminum
- Shaft: Carbon Steel
- Cover NDE: Aluminum
- Mechanical Seal: Carbon Vs. Ceramic
FEATURES
- High Efficiency and Energy Saving Design
- High Grade F - Class Insulation
- Thermal Overload Protector (TOP)
- Wide Voltage Range
- Shielded Ball Bearing
- Dynamically Balanced Rotating Parts
- Easy Maintainable Designs
- High Suction Lift
- Enhanced Safety Features
Downloads
Product Catalogue
Product Catalogue
JALHASTI
- Gardens and fountains
- Feed water to RO plants
- Domestic water supply
- Water supply to overhead tanks in bungalows
- Construction sites
- Car washing
- Lawn sprinklers
PRIMARY USAGE
Applications
- Gardens and fountains
- Feed water to RO plants
- Domestic water supply
- Water supply to overhead tanks in bungalows
- Construction sites
- Car washing
- Lawn sprinklers
SPECIFICATIONS
JALHASTI - (GOLD)
Model Jalhasti-II (Gold)
- Head Range: 6-36m
- Capacity Range: 2900 to 820 LPH
- Power Rating: 0.37 kW/0.5 HP
- Phase: Single
- Voltage Range: 180-260 Volts
- Insulation: ‘F’ Class
Model Jalhasti-I (Gold)
- Head Range: 6-50m
- Capacity Range: 4280 to 1000 LPH
- Power Rating: 0.75 kW/1.0 HP
- Phase: Single
- Voltage Range: 180-260 Volts
- Insulation: ‘F’ Class
MATERIAL OF CONSTRUCTION
- Impeller: Brass
- Delivery Casing: Cast Iron
- Motor Body: Aluminum
- Shaft: Carbon Steel
- Cover NDE: Aluminum
- Mechanical Seal: Carbon Vs. Ceramic
FEATURES
- High Efficiency and Energy Saving Design
- High Grade F - Class Insulation
- Thermal Overload Protector (TOP)
- Wide Voltage Range
- Shielded Ball Bearing
- Dynamically Balanced Rotating Parts
- Easy Maintainable Designs
- High Suction Lift
- Enhanced Safety Features
