APPLICATION

• Gardens and fountains
• Feed water to RO plants
• Domestic water supply
• Water supply to overhead tanks in bungalows
• Construction sites
• Car washing
• Lawn sprinklers

SPECIFICATIONS

JALSENA GOLD
Model Jalsena-II (Gold)

• Head Range: 6-28m
• Capacity Range (LPH): 2600 to 650 LPH
• Power Rating (HP): 0.37 kW/0.5 HP
• Phase: Single
• Voltage Range (Volts): 180-260 Volts
• Insulation: ‘F’ Class

Model Jalsena-I (Gold)

• Head Range: 6-45m
• Capacity Range (LPH): 3370 to 760 LPH
• Power Rating (HP): 0.75 kW/1.0 HP
• Phase: Single
• Voltage Range (Volts): 180-260 Volts
• Insulation: ‘F’ Class

JALSENA SILVER
Model Jalsena-II (Silver)

• Head Range: 6-28m
• Capacity Range (LPH): 2500 to 500 LPH
• Power Rating (HP): 0.37 kW/0.5 HP
• Phase: Single
• Voltage Range (Volts): 180-260 Volts
• Insulation: ‘B’ Class

Model Jalsena-I (Silver)

• Head Range: 6-41m
• Capacity Range (LPH): 3250 to 900 LPH
• Power Rating (HP): 0.75 kW/1.0 HP
• Phase: Single
• Voltage Range (Volts): 180-260 Volts
• Insulation: ‘B’ Class

FEATURES

• High Efficiency and Energy Saving Design
• High-Grade F - Class Insulation
• Thermal Overload Protector (TOP)
• Wide Voltage Range
• Shielded Ball Bearing
• Dynamically Balanced Rotating Parts
• Easy Maintainable Designs
• High Suction Lift
• Enhanced Safety Features

MATERIAL OF CONSTRUCTION

• Impeller: Brass
• Delivery Casing: Cast Iron
• Motor Body: Aluminum
• Shaft: Carbon Steel
• Cover NDE: Aluminum
• Mechanical Seal: Carbon Vs. Ceramic
