APPLICATIONS

• Gardening and Small Farm Irrigation
• Lawn Sprinklers
• Construction Site
• Domestic and Community Water Supply
• Water Transfer and Circulation

SPECIFICATIONS

• Head Range: Up to 19 metres
• Discharge Range: Up to 14.2 LPS
• Power Ratings: 0.37 to 1.1 kW/ (0.5 to 1.5 HP)
• Voltage Range: 120 to 220 volts (single phase low voltage) & 180 to 240 volts (single phase)
• Insulation: B class
• Protection: IP 44

MATERIAL OF CONSTRUCTION

• Impeller: Cast Iron
• Delivery Casing: Cast Iron
• Motor Body: Cast Iron
• Pump Shaft: C 40 Carbon Steel/Stainless Steel

FEATURES

• Wide Voltage Design
• Automatic Air Release
• Flatter Efficiency Curve
• Designed to Prevent Overloading
• Dynamically Balanced Rotating Parts
• CED – Cathode Electro Deposition Coating
• Easy Maintainable Design
• High Efficiency and Energy Saving Design
