APPLICATIONS

• Domestic and Community Water Supply
• Rural Water Supply
• Gardening and Small Farm Irrigation
• Construction Site
• Water Supplies for High Rise Buildings

SPECIFICATIONS

• Head Range : Up to 520 metres
• Discharge Range : Up to 420 LPM
• Power Ratings : 0.37 to 5.5 kW (0.5 to 7.5 HP)
• Voltage Range : 160 to 240 volts (single phase)
• 280 to 440 volts (three phase)
• Type of Cooling : Water-filled
• Insulation : B class
• Protection : IP 68

MATERIAL OF CONSTRUCTION

• Pump Housing : Stainless Steel
• Pump Shaft : Stainless Steel
• Motor Housing : Stainless Steel
• Motor Shaft : Stainless Steel
• Thrust Bearing : Carbon +SS
• Motor/Pump Bushes : Gun Metal
• Impeller : Noryl
• Diffuser : Noryl
• NRV : Cast Iron
• Suction : Cast Iron

FEATURES

• Wide Voltage Design
• High Efficiency and Energy Saving Design
• Dynamically Balanced Rotating Parts
• Longer and Trouble Free Life
• Advanced Water-cooled Motor Design
• Wide Voltage Motor Design with 100% Copper Rotor
• CED – Cathode Electro Deposition Coating
