APPLICATIONS

• Horticulture & Agriculture
• Domestic and Community Water Supply
• Sprinkler and Drip Irrigation
• Rural Water Supply
• Ground Water Supply to Water Works

SPECIFICATIONS

• Head : Up to 270 metres
• Discharge Range : Up to 2800 LPM
• Power Rating : 4.5 to 45 kW / 6 to 60 HP
• Voltage Range : 280 to 440 volts (three phase)
• Type of Cooling : Water-filled
• Insulation : B class
• Protection : IP 68

MATERIAL OF CONSTRUCTION

• Impeller : Stainless Steel
• Diffuser Casing/Bowl : Cast Iron
• Diffuser : Noryl
• Pump Shaft : Stainless Steel
• Motor Body : Stainless Steel
• Motor Shaft : Stainless Steel
• Finished Rotor : Copper
• NRV : Cast Iron
• Suction : Cast Iron
• Pump / Motor Bushes : LTB
• Thrust Bearing : Carbon + SS

FEATURES

• Wide Voltage Motor Design with 100% Copper Rotor
• Sand Fighter Design
• Dynamically Balanced Rotating Parts
• Longer and Trouble Free Life
• High Efficiency and Energy Saving Design
• CED – Cathode Electro Deposition Coating
• Designed to Prevent Overloading
• Glycol-mixed Water
