APPLICATIONS

• Domestic and community water supply
• Rural water supply
• Gardening and small farm irrigation
• Construction site
• Water supplies for high rise building

SPECIFICATIONS

• PUMPSHead Range - Up to 165 Metres
• Discharge Range - Up to 105 LPM
• Power Rating - 0.37 to 1 .5 kW (0.5 to 2.0 HP)
• Voltage Range - 140 to 240 Volts (Single Phase)
• Type of Cooling - Water Cooled
• Insulation - B - Class
• Protection - IP68Pump

MATERIAL OF CONSTRUCTION

• Pump Housing - Stainless Steel
• Pump Shaft - Stainless Steel
• Motor Housing - Stainless Steel
• Motor Shaft - Stainless Steel
• Pump Bushes - NBR
• Impeller - Noryl
• Diffuser - Noryl
• NRV - Cast Iron
• Suction - Cast Iron

FEATURES

• Wide Voltage Range Operability
• High Efficiency and Energy-saving Design
• Dynamically Balanced Rotating Parts
• Longer and Trouble Free Life
• Advanced Water Cooled Motors Designs
• Sand Fighter Designs
• CED - Cathodic Electro Deposition Coating
• Nationwide Service Network
