APPLICATIONS

• Horticulture & Agriculture
• Domestic and Community Water Supply
• Sprinkler and Drip Irrigation
• Rural Water Supply
• Ground Water Supply to Water Works

SPECIFICATIONS

• Head : Up to 427 Metres
• Capacity : Up to 650 LPM
• Power Rating : 2 .2 to 18.3 kW / 3 to 25 HP
• Voltage range : 200 to 440 volts (three phase)
• Type of cooling : Water-filled
• Insulation : B class
• Protection : IP 68

MATERIAL OF CONSTRUCTION

HHN

• Impeller: Noryl
• Diffuser: Noryl
• Diffuser Casing: Cast Iron
• Pump Shaft: Stainless Steel
• Motor Body: Stainless Steel
• Motor Shaft: Stainless Steel
• Finished Rotor: Copper
• NRV: Cast Iron
• Suction: Cast Iron
• Pump/Motor Bushes: LTB
• Thrust Bearing: Carbon + SS
• DOL: Cast Iron

HHF

• Impeller: Stainless Steel
• Diffuser: Stainless Steel
• Diffuser Casing: Stainless Steel
• Pump Shaft: Stainless Steel
• Motor Body: Stainless Steel
• Motor Shaft: Stainless Steel
• Finished Rotor: Copper
• NRV: Cast Iron
• Suction: Cast Iron
• Pump/Motor Bushes: LTB
• Thrust Bearing: Carbon + SS
• DOL: Cast Iron

FEATURES

• Wide Voltage Motor Designs with 100% Copper Rotor
• Sand Fighter Designs
• Dynamically Balanced Rotating Parts
• Longer and Trouble Free Life
• High Head Applications
• CED – Cathode Electro Deposition Coating
• Designed to Prevent Overloading
• Shielded Ball Bearing
