APPLICATIONS

• Water supply to overhead tanks in bungalows
• Domestic water supply
• Feed water to RO plants
• Construction sites
• Lawn sprinklers
• Garden and fountains
• Car washing

SPECIFICATIONS

ANISA - I (Bronze)

• Head Range: 6-24m
• Capacity Range: 2600 to 700 LPH
• Power Rating: 0.75 kW/1 HP
• Phase: Single
• Voltage Range: 160-260 Volts
• Insulation: ‘B’ Class

ANISA - II (Bronze)

• Head Range: 6-21m
• Capacity Range: 2000 to 500 LPH
• Power Rating: 0.37 kW/0.5 HP
• Phase: Single
• Voltage Range: 160-260 Volts
• Insulation: ‘B’ Class

MATERIAL OF CONSTRUCTION

• Impeller: Brass
• Delivery Casing: Cast Iron
• Motor Body: Aluminum
• Shaft: Carbon Steel
• Cover NDE: Aluminum
• Mechanical Seal: Carbon Vs. Ceramic

FEATURES

• High Efficiency and Energy Saving Design
• Wide Voltage Range
• Shielded Ball Bearing
• Dynamically Balanced Rotating Parts
• Easy Maintainable Designs
• High Suction Lift
• Enhanced Safety Features
• Cathodic Electro Deposition (CED) Coating
• Light Weight and Compact Design
