APPLICATIONS

• Domestic Water Supply
• Water Supply to Overhead Tanks
• Construction Site
• Gardens/Fountains
• Lawn Sprinklers

SPECIFICATIONS

• Depth to low water level: Up to 48 metres
• Capacity: Up to 3,600 LPH
• Power Rating: 0.37 to 1.1 kW (0.5 to 1.5 HP)
• Voltage Range: 180 to 240 Volts (Single Phase)
• Insulation: B Class
• Protection: IP 44
• Well Size: 50 mm to 115 mm

MATERIAL OF CONSTRUCTION

• Impeller: Cast Iron
• Delivery Casing: Cast Iron
• Motor Body: Cast Iron
• Pump shaft: Carbon Steel
• Jet Unit: Bronze

FEATURES

• Replaceable Wearing Parts
• Shielded Ball Bearing
• CED – Cathode Electro Deposition Coating
• Dynamically Balanced Rotating Parts
• Design to Prevent Overloading
• High Efficiency and Energy Saving Design
• Easy Maintainable Designs
