• Max Head:
    Upto 38 m

  • Max Capacity:
    Upto 11 LPH

Product Description

  • Domestic and Community Water Supply
  • Gardening and Small Farm Irrigation
  • Water Fountains
  • Construction Site
  • Water Supply to Overhead Tanks

Product Details

SPECIFICATIONS

  • Head Range: Up to 38 metres
  • Discharge Range: Up to 11 LPH
  • Power Ratings: 0.37 to 1.5 Kw (0.5 to 2 HP)
  • Voltage Range: 300 to 440 volts (three phase)
  • Insulation: B class
  • Protection: IP 68

MATERIAL OF CONSTRUCTION

  • Impeller: Cast Iron/Noryl
  • Delivery Casing: Cast Iron
  • Motor Body: Cast Iron
  • Shaft: Stainless Steel

FEATURES

  • Wide Voltage Design
  • Lightweight and Compact Design
  • Dynamically Balanced Rotating Parts
  • Replaceable Wearing Parts
  • Easy Maintainable Design
  • CED – Cathode Electro Deposition Coating
  • High Efficiency and Energy Saving Design
  • Advanced Water-cooled Motor Design

Downloads

Product Catalogue

KOS M THREE PHASE

  • Domestic and Community Water Supply
  • Gardening and Small Farm Irrigation
  • Water Fountains
  • Construction Site
  • Water Supply to Overhead Tanks

PRIMARY USAGE

APPLICATIONS

  • Domestic and Community Water Supply
  • Gardening and Small Farm Irrigation
  • Water Fountains
  • Construction Site
  • Water Supply to Overhead Tanks

SPECIFICATIONS

  • Head Range: Up to 38 metres
  • Discharge Range: Up to 11 LPH
  • Power Ratings: 0.37 to 1.5 Kw (0.5 to 2 HP)
  • Voltage Range: 300 to 440 volts (three phase)
  • Insulation: B class
  • Protection: IP 68

MATERIAL OF CONSTRUCTION

  • Impeller: Cast Iron/Noryl
  • Delivery Casing: Cast Iron
  • Motor Body: Cast Iron
  • Shaft: Stainless Steel

FEATURES

  • Wide Voltage Design
  • Lightweight and Compact Design
  • Dynamically Balanced Rotating Parts
  • Replaceable Wearing Parts
  • Easy Maintainable Design
  • CED – Cathode Electro Deposition Coating
  • High Efficiency and Energy Saving Design
  • Advanced Water-cooled Motor Design
