APPLICATIONS

• Domestic and Community Water Supply
• Gardening and Small Farm Irrigation
• Water Fountains
• Construction Site
• Water Supply to Overhead Tanks

SPECIFICATIONS

• Head Range: Up to 42 metres
• Discharge Range: Up to 9.7 LPS
• Power Ratings: 0.37 to 1.5 kW (0.5 to 2 HP)
• Voltage Range : 160 to 240 volts (single phase)
• Insulation: PP class
• Protection: IP 68

MATERIAL OF CONSTRUCTION

• Impeller: Cast Iron/Noryl
• Delivery Casing: Cast Iron
• Motor Body: Cast Iron / Stainless Steel
• Shaft: Stainless Steel

FEATURES

• Wide Voltage Design
• Lightweight and Compact Design
• Dynamically Balanced Rotating Parts
• Replaceable Wearing Parts
• Easy Maintainable Design
• CED – Cathode Electro Deposition Coating
• High Efficiency and Energy Saving Design
• Advanced Water-cooled Motor Design
