APPLICATIONS

• Sewage Pumping
• Dewatering from Basements, Multi-storeys, Shopping Malls, Godowns, etc.
• Construction Site
• Dewatering Foundation, Trenches and Pits
• Flood Water Handling

SPECIFICATIONS

• Head Range: Up to 70 metres
• Discharge Range: Up to 4800 LPM
• Power Ratings: 0.75 to 15 kW (1 to 20 HP)
• Voltage Range: 380 to 440 volts (three phase)
• Insulation: B / E class
• Protection: IP 68
• pH Value: 6.5 to 7.5
• Maximum Ambient: 40° C temperature
• Maximum Density: ≤ to 1050 kg/m3
• Consistency of Medium: < 1.2 x 103 kg/m3

MATERIAL OF CONSTRUCTION

• Impeller: Cast Iron
• Delivery Casing: Cast Iron
• Motor Body: Cast Iron
• Pump Shaft: Carbon Steel

FEATURES

• High Efficiency and Energy Saving Design
• Easy Maintainable Design
• CED – Cathode Electro Deposition Coating
• Robust Construction
• Replaceable Wearing Parts
• Dynamically Balanced Rotating Parts
