APPLICATIONS

• Air conditioning and refrigeration system
• Cooling towers
• Fire fighting
• Water supply
• Clear water handling at high pressure in industries
• Clear water handling in ETP/STP Plants
• Handling hot water in par boiled rice making machines
• Hot water handling at High Pressure in Industries

SPECIFICATIONS

• Head Range - Up to 54 M
• Discharge Range - Up to 33 LPS
• Power Rating - 1.1 - 3.7 kW (1.5 - 5.0 HP)
• Voltage Range - 350 to 440 Volts
• Protection - IP 55
• Insulation - High Grade F Class Insulation with temperature rise restricted to B Class

MATERIAL OF CONSTRUCTION

• Motor Body - Cast Iron
• Impeller - Cast Iron
• Delivery Casing - Cast Iron
• Shaft - SS
• Sealing - Mechanical Seal
• (Carbon vs Ceramic with HNBR which can withstand fluid temperature up to 120°C)

FEATURES

• Lower life cycle cost with lower operating cost
• Up to 16.6 % less energy consumption for pumping same amount of fluid
• High grade F-Class insulation with Temperature rise limited to B-Class
• High efficiencies achieved with AC induction motor design
• Cathodic Electro Deposition (CED) Coating
• Dynamically Balanced Rotating Parts
• Superior Mechanical Seal
• Replaceable Wearing Parts
• Optimum fan and fan cover design
