Applications

• Domestic and community water supply
• Water supply for high rise building
• Gardening and small farm irrigation
• Construction site
• Groundwater supply to waterworks

TECHNICAL SPECIFICATIONS

• Head Range: Up to 135 metres
• Discharge Range: Up to 350 LPM
• Power Ratings: 0.37 to 2.2 kW (0.5 to 3.0 HP)
• Voltage Range: 150 to 240 Volts (Single Phase)
• Type of Cooling: Oil Cooled
• Insulation: F Class
• Protection: IP 68

MATERIAL OF CONSTRUCTION

• Pump Housing : Stainless Steel
• Pump Shaft : Stainless Steel
• Motor Housing : Stainless Steel
• Motor Shaft : Stainless Steel
• Motor Bearing : Ball Bearing
• Pump Bushes : NBR
• Impeller : Noryl
• Diffuser : Noryl
• NRV : Cast Iron
• Suction : Cast Iron

FEATURES

• High Efficiency And Energy Saving Design
• Wide Voltage Design
• Dynamically Balanced Rotating Parts
• Designed To Prevent Overloading
• Lightweight And Compact Design
• Flatter Efficiency Curve
• Suitable For Horizontal Applications
