APPLICATIONS

• Water Supply to Overhead Tanks
• Gardens/Fountains
• Feed Water to RO
• Domestic Water Supply
• Construction Site
• Home Pressure Boosting
• Car Washing
• Lawn Sprinklers

SPECIFICATIONS

MINI 28S

• Head Range: 6 to 28 meters
• Capacity Range: 720 to 3150 LPH
• Power Ratings: 0.37 to 1.1 kW / 1.5 to 1.0 HP
• Voltage Range: 180 to 240 volts (single phase), 300 to 440 volts (three phase)

MINI 40S

• Head Range: 10 to 40 meters
• Capacity Range: 200 to 3000 LPH
• Power Ratings: 0.37 to 1.1 kW / 1.5 to 1.0 HP
• Voltage Range: 180 to 240 volts (single phase), 300 to 440 volts (three phase)

MINI 50S/50C

• Head Range: 10 to 50 meters
• Capacity Range: 400 to 3200 LPH
• Power Ratings: 0.37 to 1.1 kW / 1.5 to 1.0 HP
• Voltage Range: 180 to 240 volts (single phase), 300 to 440 volts (three phase)

MINI 50C

• Head Range: 10 to 50 meters
• Capacity Range: 520 to 2900 LPH
• Power Ratings: 0.37 to 1.1 kW / 1.5 to 1.0 HP
• Voltage Range: 180 to 240 volts (single phase), 300 to 440 volts (three phase)

FEATURES

• High Suction Lift
• High Quality Aluminium Motor Body
• TOP - Thermal Overload Protector
• Handle to Enhance Grip and Portability
• Easy Maintainable Design
• Shielded Ball Bearing
• High Efficiency and Energy Saving Design
• Dynamically Balanced Rotating Parts
