Vertical Inline Long Coupled Pump - KW-LC
-
-
Max Head:
Upto 52 m -
Max Capacity:
Upto 550 m3/hr
-
- Enquire Now
Product Description
Kirloskar vertical inline pumps are vertical single-stage in-line centrifugal pumps of the close-coupled type. These are designed for circulation of liquids in heating and air-conditioning systems. Top pull-out facility permits removal of stuffing box, and impeller without disturbance to casing or suction/discharge pipework. It includes a drain at the bottom. The dynamically balanced impeller minimises vibration and increases bearing life.
Product Details
Applications
- Water supply
- HVAC
- Air conditioning
- Hot water up to 90°C
- Drinking water
- Cooling water
- Fire Fighting applications
Specifications
- Delivery size: up to 200 mm
- Discharge Capacity (Q): 550 m3/hr (150 LPS)
- Total Head: 52 Meters
- Speed (Nominal): 1450 RPM
- Suction Pressure: 12 bar subject to maximum working pressure is 16 bar Working Pressure: 16 bar
- Temperature: : maximum upto 90° C
Features
- Vertical inline long coupled through axially split rigid coupling
- Suction and Delivery nozzles are cast integral with volute and are in-line. Suction and delivery flanges are cast integral
- Volute is designed with smooth fluid flow passages.
- Machined surface and mounting holes are provided on the pump casing for ease of pump installation.
- Impeller is enclosed type. It is dynamically balanced which ensures the smooth operation of the pump.
- Pump Shaft is designed for the toughest service. The critical speed of the shaft is sufficiently above the operating speed.
- Efficient water pumps with MEI of over 0.7, in accordance with Eco-design requirements.
